Conveyor / transfer belt for auto tire industry

Our company designs and produces cut-resistant conveyor belt according to characters of parts and components conveying on the high-speed press line of auto industry.

Such type of conveyor belt uses specially treated polyester fiber woven fabric as bearing skeleton, one side or both sides coated with PVC or PU as conveying side or composed with carpet fabric.

Such type of conveyor(transfer) belt features high strength, low elongation, good elasticity, wide working temperature, stable running, long durability.etc. The extraordinary property is it’s high tensile strength with cut resistance, impact resistance, which become the idea complement products of auto part press lines.

Model: SM25

Thickness:4.0mm

Tensile force for 1% elongation:10N/mm

Minimum pulley diameter:100mm

Maximum production width: 2000mm

Model: SU22-26P

Thickness:4.0mm

Tensile force for 1% elongation:12N/mm

Minimum pulley diameter:100mm

Maximum production width: 2000mm

Model: SP32-07

Thickness:2.8mm

Tensile force for 1% elongation:13N/mm

Minimum pulley diameter:100mm

Maximum production width: 3000mm

Model: SP42-14

Thickness:4.0mm

Tensile force for 1% elongation:16N/mm

Minimum pulley diameter:150mm

Maximum production width: 3000mm

Model: SP32-14

Thickness:2.8mm

Tensile force for 1% elongation:13N/mm

Minimum pulley diameter:100mm

Maximum production width: 3000mm

Model: SP22-07B

Thickness:1.3mm

Tensile force for 1% elongation:8N/mm

Minimum pulley diameter:250mm

Maximum production width: 3000mm

Model: SP22-07

Thickness:2.8mm

Tensile force for 1% elongation:8N/mm

Minimum pulley diameter:100mm

Maximum production width: 3000mm

Nanjing Skypro Rubber & Plastic Co., Ltd., is a professional manufacturer leading in designing, producing and exporting various types of rubber and plastic belt including rubber sheeting, rubber matting, rubber tile as well as other nonstandard rubber products.

Our products range from Commercial Grade rubber sheeting to specialty grades including EPDM, Silicone Rubber and Fluorine Rubber(Dupont’s FKM) sheets, we do also involves in other sheets such as Natural Rubber, SBR, NBR, which feature oil-resistance acid and alkali-resistance, water-proof, fire-retardant, insulation, conductive and and anti-slid All the above grades are supplied in multiple colors in order to optimize our clients’ specific requests.
The light duty PVC (PU,PE,TPU,TPEE, silicone, PTFE) conveyor (transfer, transmission ) belt is a new product lines which we launched two years before, which are mainly used indoor for processing lines of tobacco, logistics, wood, stone, electronics, vegetable and food processing industries. We are able to survey, design, install and maintain custom made conveyor and transfer belt for special applications.

Our advanced staffs and engineers persistently supplying our clients the competitive price, premium quality, as well as considerate after-sale services. Our sales network extend to more than 30 countries covering South East Asia, North America, Europe and other regions throughout the world.

We are sticking to developing advanced technologies in order to meet the gradually arising new demands from industries of chemical engineering, mechanical, electronics, auto, construction, pharmaceutical etc.,
Worldwide importers, wholesalers, distributors are welcome to visit our factories and discuss long-term partnership. Your gracious comments will be our fresh motivation and encouragement to driving us to be top supplier in this world.
